Copper Clad Steel Wire and Strand

Copper Clad Steel Wire (CCS) is a new type of bimetal composite material formed through electroplating method (taking steel wire as the core and plating the copper layer evenly on the surface of the steel core) and cladding method (cladding copper stripe evenly and continuously on the outer surface of the steel core).

Further processing can be carried out on CCS, which includes tin plated, silver plated, lacquer, and stranding, nail making, bright – annealing braiding, etc.

Dia Range: 0.079mm~20mm

Electrical Conductivity: 15%~60%

Standard: ASTMB869, ASTMB452, ASTMB227 or as customer’s standards

Application:

  • Inner conductor of CATV drop wire
  • Trolly wire for rail lines
  • Inner conductor of telephone drop wire
  • Shield wire for power cable
  • Inner conductor of computer LAN cable, field wire
  • Ground wire for power industry
  • Conductor of various electronic components
  • Strengthening bar for automobile tires
  • Trolly wire for power transmission and telephone circuit
  • Gun nails, sealing nail and various kinds of stationery staplers
