Copper Clad Aluminum Wire and Strand

Copper Clad Aluminum Wire (CCA) is a bimetal composite material formed by cladding, welding, and drawing the copper stripe on the outer layer of the aluminum.

Copper Electroplated Aluminum Wire is formed through electro deposition, which plates the copper layer evenly on the aluminum bar so as to form interatomic force on the interface between the two metals, making them into a integrated material.

It possesses good, high strength, and strong solderability of copper, as well as the low density and good workability of aluminum. Besides, it has the advantages of uniform density, high compactness and high flexibility.

Further processing can be carried out on CCA, which includes tin plated, silver plated and stranding etc.

Dia Range: 0.065mm~10mm

Standard: ASTMB566 or as customer’s standards

Application:

  • High-frequency Signal Transmission:

Preferred inner conductor material for cable TV coaxial cables

50Ω RF cables

Inner conductor material for flexible RF coaxial cables

Inner conductor material for computer cables and other data cables

Inner conductor material for micro-coaxial cables

  • Power Transmission:

Enameled wires

Conductor material for power cables

Inner conductor for control cables

Inner conductor for automotive and locomotive cables

Conductor material for building wiring cables

Conductor material for busbars and similar components

Fuses

RF shielding meshes

  • Special Magnet Wires:

For electronic computers

For mobile communication equipment

For coils or windings in aerospace and military instruments
